Welded Flange End Angle Globe Valve, A182 F316, DN25, PN100, RF
Key Specifications / Features
Model No.: Hits: 83
Welded Flange End Angle Globe Valve Maker in China: Welded Flange End Angle Globe Valve, ASTM A182 F316, DN25, PN100, RF, EN ISO 15761, FF EN558-1.
Request a quote
Share
Tags:
Detail Information
Name: Angle type globe valve with welded flange ends.
Design: EN ISO 15761.
Body: ASTM A182 F316.
Nominal size: DN25.
Nominal class: PN100.
End connection: RF.
Face to face: EN558-1.
Test and inspection: EN12266-1.
Technical parameters and characteristics
Design: EN ISO 15761.
Body: ASTM A182 F316.
Nominal size: DN25.
Nominal class: PN100.
End connection: RF.
Face to face: EN558-1.
Test and inspection: EN12266-1.
Technical parameters and characteristics
| Product | Small size globe valve |
| Nominal diameter | 1/4 Inch - 4 Inch |
| Design temp. | -196℃ - 573℃ |
| Design pressure | Class 150 - 4500 |
| Material | Forged carbon steel, Stainless steel, Alloy steel, Bronze |
| Design standard | API 602, BS 5352 |
| Face to face | Manufacture standard, ASME B16.10 |
| Connection end | NPT, SW, BW, Flange |
| Test standard | API 598, ISO 5208 |
| Operation | Hand wheel, electric |
| Application | Power station, petroleum, chemical engineering |
| Function 1 | bolted bonnet, welded bonnet, pressure seal bonnet |
| Function 2 | plug disc, needle disc |
| Function 3 | full bore, reduce bore |
| Function 4 | Integral flanged ends, welded on flanged ends |
