ASTM A216 WCB T Type Strainer, 12IN, CL150, ASME B16.34, RF
Key Specifications / Features
Model No.: 1-2
Hits: 840
China ASTM A351 CF8 T Type Strainer Manufacturer Baltic Offers ASTM A216 WCB T Type Strainer, 12IN, CL150, ASME B16.34, RF Ends, FF ASME B16.10.
Tags:
Detail Information
Valve description:
Name: T type strainer.
Design: ASME B16.34.
Body: ASTM A216 WCB.
Nominal size: 12 Inch.
Nominal class: Class 150.
Connection ends: RF Flanged ends.
Face to face: as per ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
Name: T type strainer.
Design: ASME B16.34.
Body: ASTM A216 WCB.
Nominal size: 12 Inch.
Nominal class: Class 150.
Connection ends: RF Flanged ends.
Face to face: as per ASME B16.10.
Test and inspection: API 598.
Technical parameters and characteristics
| Product | T type strainer | |
| Nominal diameter | NPS 2”～24” | DN50～DN600 |
| Design temp. | -196℃ ～ 593℃ | |
| Design pressure | class 150 ～ 300 | PN 10 ～ PN40 |
| Material | A216 WCB, WCC; A217 WC6, WC9, C5; A352 LCB, LCC; A351 CF8, CF8M, CF3M, CF8C, CN3MN, CK3MCUN, CN7M; A890 4A(CD3MN), 5A(CE3MN), 6A(CD3MWCuN); ASTM B 148 C95800, C95500 | |
| Design standard | ASME B16.34 | |
| Face to Face | ASME B16.10, manufacture standard | |
| Connection end | RF, BW | |
| Test standard | API 598 | |
| Operation | NO | |
| Application | Petroleum, chemical, water supply and drainage, water treatment | |
| Function 1 | On-line repair + maintenance | |
| Function 2 | with a plug drain | |
| Function 3 | 2-layer screen, strong enough, not damage | |
| Function 4 | bolted cover, bonnet gasket: SS + graphite (spiral wound) | |
