Baltic delivered a big quantity of EN1984/DIN 3352 gate valves

  • 05 15, 2018
Dated April 25th, we delivered a big quantity of EN1984/DIN 3352 gate valves to one of our customers in Austria. The customer buys a large quantity of valves from us every year.

Generally:

GATE VALVE, design as per EN1984/DIN 3352
  • outside screw and yoke
  • with hand wheel/gearbox
  • body/bonnet GS-C25
  • trim 13%Cr
  • flanged according EN 1092-1 type B1 for PN40 and B2 for PN63 and PN100
  • face to face dim. acc. EN558-1 type 26 (DIN 3202 F7)
  • painting: body/bonnet (silver) and hand wheel (blue)
  • including inspection certificate EN 10204-3.1B for shell test and tightness test
  • including material certificate acc. EN 10204-3.1B for body and bonnet
  • valves have to be CE-marked (CE 0035)

Size Pressure Qty Operation
DN80 PN40 5 Hand wheel
DN100 PN40 20 Hand wheel
DN125 PN40 15 Hand wheel
DN150 PN40 20 Hand wheel
DN200 PN40 15 Hand wheel
DN250 PN40 5 gearbox

DN100 PN63 15 Hand wheel
DN125 PN63 20 Hand wheel
DN150 PN63 20 Hand wheel
DN300 PN63 3 gearbox

DN80 PN100 2 Hand wheel
DN100 PN100 3 Hand wheel
DN125 PN100 8 Hand wheel


EN1984/DIN 3352 gate valves EN1984/DIN 3352 gate valves

EN1984/DIN 3352 gate valvesEN1984/DIN 3352 gate valves


EN1984/DIN 3352 gate valvesEN1984/DIN 3352 gate valves


EN1984/DIN 3352 gate valvesEN1984/DIN 3352 gate valves


EN1984/DIN 3352 gate valves
